1
Engine displacement
650
2
Year
2005
3
Model
FS 650 C
4
Trim
FS 650 C
5
Parts Catalog
SHOCK ABSORBER (PARTS)
6
Parts Diagram
Parts Catalog
SHOCK ABSORBER
by
SHOCK ABSORBER (PARTS)
SHOCK ABSORBER (PARTS)
36
20
4
4
3
3
16
11
11
19
14
21
18
6
48
32
8
13
25
46
46
15
37
37
31
31
47
47
45
5
5
26
48
48
2
29
42
44
43
1
35
28
30
27
27
12
40
40
40
40
93
80
71
94
65
54
56
56
56
56
54
56
56
54
54
56
56
56
56
56
56
56
56
56
56
54
56
50
50
50
50
50
50
81
76
75
75
79
73
74
85
82
82
62
83
83
86
84
84
91
57
49
61
96
70
64
87
66
95
88
98
90
60
97
72
51
63
58
99
1
SHOCK ABS.CASE 30,5 B21 82GR03
50180357
250,47€ Unit Price incl. VAT
2
Compression cpl.
50180213S6
120,82€ Unit Price incl. VAT
3
ADAPTOR-BUSH 12X26
46180061
7,38€ Unit Price incl. VAT
4
Seal ring 19,5x26x3
46180003
4,78€ Unit Price incl. VAT
5
Round-wire snap ring 25x1
50180168
3,09€ Unit Price incl. VAT
6
Ball joint bearing 15x25x13
50180005
25,59€ Unit Price incl. VAT
8
HS cylinder-head screw R1/8 l8
50180095
5,02€ Unit Price incl. VAT
11
O-ring 45x2 NBR70 siliconized
46810340
1,88€ Unit Price incl. VAT
12
WP CAUTION (PDS KTM) 58X83
52000041
2,24€ Unit Price incl. VAT
13
RESERVOIR SCREW L140 GREY
50180096
50180096S
127,66€ Unit Price incl. VAT
14
O-ring 35x5 Viton70
46811043
3,39€ Unit Price incl. VAT
15
Piston 46mm reservoir
50180108
22,08€ Unit Price incl. VAT
16
Pistonring 42,5x45,5x3,9
46810324
20,57€ Unit Price incl. VAT
18
RESERVOIR CAP D=46
46811209
22,26€ Unit Price incl. VAT
19
O-ring 5,28x1,78 NBR70 black
46810893
1,15€ Unit Price incl. VAT
20
HS lock screw M5x6
36120151
3,69€ Unit Price incl. VAT
21
Rubber cap do not open 22x5,5
46811208
4,78€ Unit Price incl. VAT
25
O-ring 52x2 NBR70
50180097
1,88€ Unit Price incl. VAT
26
Springwasher 8,2x16x0,6
50180177
1,75€ Unit Price incl. VAT
27
NEEDLE D=11,4 D=7,6 L=57
50180444
11,07€ Unit Price incl. VAT
27
NEEDLE D=11,4 D=7,8 L=57
50180448
11,07€ Unit Price incl. VAT
28
SCREW CAP M20X1 D=11,5 H=5
50180437
13,37€ Unit Price incl. VAT
29
LOCK WASHER
50180270
17,91€ Unit Price incl. VAT
30
TUBE L=195 PDS
50180442
98,74€ Unit Price incl. VAT
31
CIRCLIP 50X1,5
50180133
5,02€ Unit Price incl. VAT
32
Spring guide 54,15x60x40
50180081
18,51€ Unit Price incl. VAT
35
SPRING RETAINER M56X1
50180433
45,07€ Unit Price incl. VAT
36
AH SCREW DIN0912-M 5X30
0912050303
1,39€ Unit Price incl. VAT
37
Intermediate washer spring 61,
50180114
8,23€ Unit Price incl. VAT
40
SPRING 250 80N/MM D=12,5 (62)
91210004
129,59€ Unit Price incl. VAT
40
SPRING PDS6-260 71,5-90,5N/MM
91210015
129,59€ Unit Price incl. VAT
40
SPRING PDS7-260 76-95N/MM
91210016
129,59€ Unit Price incl. VAT
40
SPRING PDS8-260 81-99,5N/MM
91210017
129,59€ Unit Price incl. VAT
42
Round-wire snap ring 58,5x2
50180273
5,02€ Unit Price incl. VAT
43
SPRING RETAINER D=80 2003
50180355
41,02€ Unit Price incl. VAT
44
O-ring 66,27x1,78 Viton70
50180352
4,30€ Unit Price incl. VAT
45
Piston rod nut 16x1
50180141
12,34€ Unit Price incl. VAT
46
O-ring 44x,17x1,78 Viton70
50180099
4,30€ Unit Price incl. VAT
47
Piston ring 47,95x49,95x8
50180135
17,48€ Unit Price incl. VAT
48
SHIM 16X28X0,30
50180072
2,06€ Unit Price incl. VAT
48
Shim 21x36x0,25
50180209
2,36€ Unit Price incl. VAT
48
WASHER 16X21X1
50180210
2,06€ Unit Price incl. VAT
49
Piston 16,05x49,6x13,5 4,5/7
50180197
40,17€ Unit Price incl. VAT
50
Shim 16x22x0,30
50180036
2,06€ Unit Price incl. VAT
50
SHIM 16X30X0,30
50180073
2,36€ Unit Price incl. VAT
50
SHIM 16X32X0,30
50180074
2,36€ Unit Price incl. VAT
50
SHIM 16X34X0,30
50180075
2,36€ Unit Price incl. VAT
50
SHIM 16X36X0,30
50180076
2,36€ Unit Price incl. VAT
50
SHIM 16X38X0,30
50180077
2,36€ Unit Price incl. VAT
50
SHIM 16X40X0,30
50180078
2,66€ Unit Price incl. VAT
51
SANDWICH BUSH D26XD16X14.5/11
50180436
16,34€ Unit Price incl. VAT
54
Shim 16x20x0,30
50180034
2,06€ Unit Price incl. VAT
54
SHIM 16X28X0,15
50180045
2,06€ Unit Price incl. VAT
54
Shim 16x28x0,2
50180054
2,06€ Unit Price incl. VAT
54
Shim 16x32x0,2
50180056
2,36€ Unit Price incl. VAT
54
Shim 16x34x0,2 y5
50180057
2,36€ Unit Price incl. VAT
54
SHIM 16X36X0,25
50180067
2,36€ Unit Price incl. VAT
56
Shim 16x21x0,30
50180035
2,06€ Unit Price incl. VAT
56
Shim 16x22x0,30
50180036
2,06€ Unit Price incl. VAT
56
SHIM 16X23X0,30
50180037
2,06€ Unit Price incl. VAT
56
SHIM 16X34X0,15
50180048
2,36€ Unit Price incl. VAT
56
SHIM 16X36X0,15
50180049
2,36€ Unit Price incl. VAT
56
Shim 16x34x0,2 y5
50180057
2,36€ Unit Price incl. VAT
56
SHIM 16X36X0,20
50180058
2,36€ Unit Price incl. VAT
56
SHIM 16X38X0,20
50180059
2,36€ Unit Price incl. VAT
56
Shim 16x40x0,2
50180060
2,66€ Unit Price incl. VAT
56
Shim 16x52x0,2
50180061
2,66€ Unit Price incl. VAT
56
SHIM 16X28X0,25
50180063
2,06€ Unit Price incl. VAT
56
SHIM 16X30X0,25
50180064
2,36€ Unit Price incl. VAT
56
SHIM 16X32X0,25
50180065
2,36€ Unit Price incl. VAT
56
SHIM 16X34X0,25
50180066
2,36€ Unit Price incl. VAT
56
SHIM 16X44X0,25
50180071
2,66€ Unit Price incl. VAT
57
REBOUND DISC D=34, H=8
50180196
15,85€ Unit Price incl. VAT
58
PISTON 6+6X3,5/4,5
50180446
33,94€ Unit Price incl. VAT
60
PISTON ROD D=18 L=151 M16X1
50180431
117,19€ Unit Price incl. VAT
61
BUSH M8X1
50180200
8,83€ Unit Price incl. VAT
62
O-ring 7x1,5 Viton70 green
50180157
3,15€ Unit Price incl. VAT
63
NEEDLE SEAT M8X1 D=5,5 05
50180439
10,41€ Unit Price incl. VAT
64
TUBE M18X1 L=151,5
50180264
6,96€ Unit Price incl. VAT
65
O-ring 8x2 NBR70
48600049
1,33€ Unit Price incl. VAT
66
Bush 5/8,2/7x9,5/16,8x23
50180279
10,71€ Unit Price incl. VAT
70
NEEDLE L=175
50180261
18,39€ Unit Price incl. VAT
71
O-ring 2,2x1,6 Viton75 green
46811265
3,15€ Unit Price incl. VAT
72
ADAPTOR CPL. D=50 H=29
50180435S
50180435S1
52,45€ Unit Price incl. VAT
73
Rubber pad rebound 27x48x8 NBR
50180107
5,87€ Unit Price incl. VAT
74
Washer 18,5x43,7x6
50180113
9,08€ Unit Price incl. VAT
75
Washer 18x22,5x1,5 plastic
50180102
7,44€ Unit Price incl. VAT
76
X-ring 18x2,62 Viton70
50180101
5,69€ Unit Price incl. VAT
79
O-ring 41x5 NBR70
50180103
1,88€ Unit Price incl. VAT
80
Guide bushing 18x20x12
46180119
7,44€ Unit Price incl. VAT
81
Dirt scarper 18mm
50180082
7,44€ Unit Price incl. VAT
82
ADAPTOR-BUSH KGW 32X10X26
50180153
8,71€ Unit Price incl. VAT
83
Seal ring 22x32x4
50180159
4,78€ Unit Price incl. VAT
84
Round-wire snap ring 32x1
50180175
4,24€ Unit Price incl. VAT
85
Round-wire snap ring 53x1,75
50180126
5,02€ Unit Price incl. VAT
86
Cap 50,1x17,5 h6
50180165
24,74€ Unit Price incl. VAT
87
Rubber pad 17,2x45,2x40 black
50180276
22,51€ Unit Price incl. VAT
88
HH locking nut M18x1 h5 WAF24
50180283
11,07€ Unit Price incl. VAT
90
Footpart M18x1 h54 natural
50180358
367,36€ Unit Price incl. VAT
91
Ball joint bearing 16x32x21
50180179
27,59€ Unit Price incl. VAT
93
Steel ball d3
40540603
2,66€ Unit Price incl. VAT
94
Spring (1,7) l7,9
48600028
4,36€ Unit Price incl. VAT
95
HH screw M14x9
50180281
10,71€ Unit Price incl. VAT
96
O-ring 4x1,5 NBR70
50180222
1,33€ Unit Price incl. VAT
97
Adjustment screw slot
50180434
10,47€ Unit Price incl. VAT
98
SHOCK ABSORBER FLUID 5 LT '03
50180342S1
105,75€ Unit Price incl. VAT
99
REPAIR-KIT GASKET 5018 PDS 03
R12008
93,41€ Unit Price incl. VAT

Find the detailed SHOCK ABSORBER (PARTS) HUSQVARNA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original HUSQVARNA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.

Other Parts for FS 650 C

FRONT FORK / TRIPLE CLAMP

FRONT FORK / TRIPLE CLAMP

for FS 650 C from 2005

FRONT FORK / TRIPLE CLAMP

FRONT FORK / TRIPLE CLAMP

for FS 650 C from 2005

FRONT FORK (PARTS)

FRONT FORK (PARTS)

for FS 650 C from 2005

FRONT FORK (PARTS)

FRONT FORK (PARTS)

for FS 650 C from 2005

FRONT FORK (PARTS)

FRONT FORK (PARTS)

for FS 650 C from 2005

HANDLEBAR / CONTROLS

HANDLEBAR / CONTROLS

for FS 650 C from 2005

FRAME

FRAME

for FS 650 C from 2005

SIDE / MAIN STAND

SIDE / MAIN STAND

for FS 650 C from 2005

SHOCK ABSORBER

SHOCK ABSORBER

for FS 650 C from 2005

SHOCK ABSORBER (PARTS)

SHOCK ABSORBER (PARTS)

for FS 650 C from 2005

SHOCK ABSORBER (PARTS)

SHOCK ABSORBER (PARTS)

for FS 650 C from 2005

SWINGARM

SWINGARM

for FS 650 C from 2005

EXHAUST

EXHAUST

for FS 650 C from 2005

EXHAUST

EXHAUST

for FS 650 C from 2005

AIR FILTER

AIR FILTER

for FS 650 C from 2005

TANK / SEAT

TANK / SEAT

for FS 650 C from 2005

PLASTICS

PLASTICS

for FS 650 C from 2005

STICKERS

STICKERS

for FS 650 C from 2005

FRONT WHEEL

FRONT WHEEL

for FS 650 C from 2005

FRONT WHEEL

FRONT WHEEL

for FS 650 C from 2005

REAR WHEEL

REAR WHEEL

for FS 650 C from 2005

REAR WHEEL

REAR WHEEL

for FS 650 C from 2005

REAR WHEEL

REAR WHEEL

for FS 650 C from 2005

WIRING HARNESS

WIRING HARNESS

for FS 650 C from 2005

WIRING HARNESS

WIRING HARNESS

for FS 650 C from 2005

ACCESSORIES

ACCESSORIES

for FS 650 C from 2005

FRONT BRAKE MASTER CYLINDER

FRONT BRAKE MASTER CYLINDER

for FS 650 C from 2005

FRONT BRAKE MASTER CYLINDER

FRONT BRAKE MASTER CYLINDER

for FS 650 C from 2005

REAR BRAKE MASTER CYLINDER

REAR BRAKE MASTER CYLINDER

for FS 650 C from 2005

FRONT BRAKE CALIPER

FRONT BRAKE CALIPER

for FS 650 C from 2005

FRONT BRAKE CALIPER

FRONT BRAKE CALIPER

for FS 650 C from 2005

REAR BRAKE CALIPER

REAR BRAKE CALIPER

for FS 650 C from 2005

HEADLIGHT / TAIL LIGHT

HEADLIGHT / TAIL LIGHT

for FS 650 C from 2005

IGNITION SWITCH

IGNITION SWITCH

for FS 650 C from 2005

SPECIFIC TOOLS (ENGINE)

SPECIFIC TOOLS (ENGINE)

for FS 650 C from 2005

CRANKCASE

CRANKCASE

for FS 650 C from 2005

CLUTCH COVER

CLUTCH COVER

for FS 650 C from 2005

BALANCER SHAFT

BALANCER SHAFT

for FS 650 C from 2005

CYLINDER

CYLINDER

for FS 650 C from 2005

CYLINDER / HEAD

CYLINDER / HEAD

for FS 650 C from 2005

CRANKSHAFT / PISTON

CRANKSHAFT / PISTON

for FS 650 C from 2005

ENGINE VENT

ENGINE VENT

for FS 650 C from 2005

CARBURETOR

CARBURETOR

for FS 650 C from 2005

CLUTCH

CLUTCH

for FS 650 C from 2005

GEARBOX MAIN SHAFT

GEARBOX MAIN SHAFT

for FS 650 C from 2005

GEARBOX MAIN SHAFT

GEARBOX MAIN SHAFT

for FS 650 C from 2005

GEARBOX COUNTERSHAFT

GEARBOX COUNTERSHAFT

for FS 650 C from 2005

KICK STARTER

KICK STARTER

for FS 650 C from 2005

GEAR SHIFTING MECHANISM

GEAR SHIFTING MECHANISM

for FS 650 C from 2005

COOLING SYSTEM

COOLING SYSTEM

for FS 650 C from 2005

COOLING SYSTEM

COOLING SYSTEM

for FS 650 C from 2005

VALVES

VALVES

for FS 650 C from 2005

TIMING

TIMING

for FS 650 C from 2005

OIL PUMP

OIL PUMP

for FS 650 C from 2005

IGNITION SYSTEM

IGNITION SYSTEM

for FS 650 C from 2005

ELECTRIC STARTER MOTOR

ELECTRIC STARTER MOTOR

for FS 650 C from 2005

Husqvarna FS 650 C 2005

FS 650 C

FS 650 C

Model : FS 650 C

Engine capacity : 650

Year : 2005

WW-EU

Europe

New and OEM parts
International Shipping
Official price Husqvarna
A team of experts at your service
Secure Payment
By your side since 2001
Customer Reviews
4.1 /5
929 Reviews
View all reviews
Spare parts catalogue for all brands
